"Hatsuyuki" ICE SHAVER

CUBE ICE SHAVER

HC-77B

Large Capacity Cube Ice Shaver

Easy for operation and maintenance.
The inlet cover can be removed by just lifting it up straight.

  • HC-77B

Operation

Dice-shaped cube ice is recommended to make soft and fine shaved ice.

Specifications
Dimensions(WxDxH) 290 W x 360 D x 499mm H, 11-1/2" W x 14-1/2" D x 19-3/4" H
Net Weight 17.5Kgs/38.5Lbs.
Electrical 220V, 50Hz/60Hz, 1Ph - 220W
115V, 60Hz, 1Ph - 255W
240V, 50Hz, 1Ph - 300W
110V, 60Hz, 1Ph - 240W
Ice Hopper Capacity 70-77 pcs.(3x3x3cm cube ice)
Shaving Capacity 2.5Kgs(50Hz)/3.0Kgs(60Hz) per min, 6.6Lbs (60Hz) per min

HC-8E

Model HC-8E uses the food zone plastic covers and parts confirmed safe as per NSF standards and the covers are uninflammable as per UL safety standards. For safety, the machine does not start while the ice inlet cover is open.

The motor and the sharp/hard stainless blade are made in Japan for durability.

  • HC-77B
  • UL
  • NSF

HC-8E is listed on UL and NSF certifications.

Operation

Dice-shaped cube ice is recommended to make soft and fine shaved ice.

How to Use

  • 1Open the lid and put in ice cubes.
  • 2Close the lid.
  • 3Adjust the texture of shaved ice.(Shaving will not start while the lid is open.)
  • 4Switch on.(Adjust the texture of shaved ice during operation.)
Specifications
Dimensions(WxDxH) 340 W x 390 D x 430mm H, 13-5/16" x 15-1/4" x 17"
Net Weight 22kgs/47Lbs.
Electrical 115V, 1Phase, 60Hz., 3.8A, 255W
Ice Hopper Capacity 70 pcs. of 1" x 1" x 1" ice cube
Ice Shaving Capacity 6.0Lbs. per minute

HC8EDC

12V DC Battery-operated Cube Ice Shaver

Model HC8EDC uses the food zone plastic covers and parts confirmed safe as per NSF standards. For safety, the machine does not start while the ice inlet cover is open. The stainless blade is made in Japan for its long lasting sharpness.

Recommended for outdoor use with a rechargeable deep cycle (marine) battery ;
perfect for cart businesses, amusement parks, baseball/football fields, and concession trailers. A 40AH (amp/hour) deep cycle marine battery, for example, allows the HC8EDC to shave 400 or more servings of shaved ice by a single overnight charge.
The electric specifications of Model HC8EDC are DC 12V 16A 190W.
Please read the following information on DC 12V Battery/Charger.

  • HC8EDC
  • NSF

Operation

Dice-shaped cube ice is recommended to make soft and fine shaved ice.

How to Use

  • 1Open the lid and put in ice cubes.
  • 2Close the lid.
  • 3Adjust the textureof shaved ice.(Shaving will not start while the lid is open.)
  • 4Switch on.(Adjust the texture of shaved ice during operation.)
Specifications
Dimensions(WxDxH) 340 W x 390 D x 430mm H, 13-5/16" x 15-1/4" x 17"
Net Weight 22kbs/47Lbs.
Electrical DC 12V, 16A, 190W
Ice Hopper Capacity 70 pcs. of 1" x 1" x 1" ice cube
Ice Shaving Capacity 6.0Lbs. per minute

HC-S32A

  • Compact and easy for operation.
  • Shaved ice is not crunchy, but fluffy, light and flavorful.
  • Operation stops automatically when the lid is opened.
  • Easy for removing food-zone parts to sanitize.
    -Easily accessible for cleaning under HACCP concept and in compliance with accessibility (structure) for cleaning by NSF standards (USA).
  • This meets the standards in Europe-CE MARK.
  • HC-S32A
  • CE

Operation

Dice-shaped cube ice is recommended to make soft and fine shaved ice.

How to Use

  • 1Open lid and put in ice cubes.
  • 2Close lid, and adjust blade for desired ice consistency.
  • 3Switch on.

Removing Food-Zone Parts to Sanitize

Most of all the food-zone parts are disassembled by hand easily. You just need to use a screw driver for removing Rotary Hopper,than Head cover, water-proof cover, and ice cute are removed by hand.

Specifications
Dimensions(WxDxH) 306 W x 402 D x 429mm H 12" W x 15-7/8" D x 17"H
Shaving capacity (per min) 1.4Kgs(50Hz)/1.7Kgs(60Hz)
Net weight 15Kgs/33Lbs
Electrical 220V, 50/60Hz, 1Ph.
115V, 60Hz, 1Ph.
Ice hopper capacity About 35 pc .(3cm cube ice)

HC-18C

The smallest ice shaver among Hatsuyuki commercial shavers.
Compact and easy to install in a small space.
Almost 2 servings (16 ice cubes) as its capacity for shaved ice snow cone.

  • HC-18C
  • HC-18C

Operation

Dice-shaped cube ice is recommended to make soft and fine shaved ice.

Specifications
Dimensions(WxDxH) 230 W x 266 D x 392mm H
Net Weight 9Kgs
Electrical 220V, 50Hz(60Hz), 140/160W
Shaving Capacity 1.0/1.3Kgs/min (220V, 50Hz)
Ice Hopper Capacity About 18 pcs.(3cm cube ice)
